The TLT615A is a multi-functional lifting platform designed for EV battery pack replacement as well as the maintenance of vehicle transmissions and engines.
Equipped with a dual scissor arm and dual-cylinder lifting system, supporting a maximum load capacity of 22,046 lb (10,000 kg) under optimal conditions in a straight-line configuration.
Powered by an AC asynchronous motor (220V, 0.75KW, 13Mpa) and an aluminum alloy power unit, featuring a CE-certified transformer for enhanced reliability in various operating conditions.
Designed with an upper floating platform and a lower angle adjustment frame for flexibility and precise adjustments.
Features a step-by-step limit rack design combined with an electromagnetic switch-driven locking tongue and a travel limit switch, significantly improving operational safety.
A throttle valve is installed at the front end of the oil pipe components to ensure maximum oil circuit safety.
Equipped with two curved PU straight wheels and two curved PU universal wheels with brakes, offering smooth steering and easy mobility.
Includes a handheld control box with magnetic button controls for effortless lifting and lowering, ensuring safe and intuitive operation.
The tabletop is densely perforated with tooling holes, allowing for the integration of optional tabletop head components to suit various tasks and applications.
Streamlines battery pack replacements and maintenance procedures, improving overall productivity while maintaining a high level of safety.
Rated Lifting Weight: 3300 lb
Lifting Height: 74.41 in
Platform Length: 70.87 in
Platform Width: 31.50 in
Size: 100.39 x 38.19 x 43.31 in
Platform Floating Distance: 4 directions ± 1.18 in
Platform Swing X-Axis Angle: 4°
Platform Swing Y-Axis Angle: 4°
Pallet Height: 6.30 - 8.27 in
Lifting Time: 20-30 s
Lowering Time: 10-120 s adjustable
Working Voltage: 220V 1PH 60Hz
Power: 10.75KW
Package Size: 92.52 x 40.55 x 33.46 in (wooden box)
Net Weight: 1102.31 lb
Gross Weight: 1212.54 lb
